DIN17102 StE420 Steel Plates are used in Construction of Bridges, Highway Construction and Other Engineering construction
DIN17102 StE420 Carbon Structural Steel Plate, DIN17102 StE420 High Strength Structural Steel Plate, DIN17102 StE420 Carbon Steel plate, DIN17102 StE420 Structural Steel Plate.
|
Grade |
Chemical Composition(%) |
||||
|
C |
Mn≥ |
Si |
P |
S |
|
|
DIN17102 StE420 |
0.20 |
1.00-1.70 |
0.10-0.60 |
0.035 |
0.030 |
|
Grade |
Mechanical Property |
|
|||
|
Tensile Strength(MPa) |
Yield Strength(MPa) |
% Elongation in 2 in.(50mm) min |
Impacting Test Temperature(°C) |
|
|
|
DIN17102 StE420 |
530-680 |
345-420 |
19 |
+20, 0, -20 |
|
UT (Ultrasonic examination),AR(As Hot Rolled only),TMCP(Thermal Mechanical Control Processing),N(Normalized),Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35) ,Charpy V-Notch Impact Test,HIC test, NDT ,PWHT( Simulated Post Weld Heat Treatment),NACE0175,The Third Party Test (Such as SGS Test), Coated or Shot Blasting and Painting.
